PZT3904-TP Micro Commercial Components (MCC)

PZT3904-TP , Micro Commercial Components (MCC)

Manufacturer:	Micro Commercial Components (MCC)
Mfr.Part #:	PZT3904-TP
Package:	SOT-223-4
RoHS:
Datasheet:	PDF For PZT3904-TP
Description:	Bipolar Transistors - BJT NPN 60Vcbo 40Vceo 6Vebo 200mA 1W

Request for Quotation In Stock: 874028

Warm Tips: Please fill out the below form and we will contact you as soon as possible.

*Quantity：

*Your Name：

*Email Address：

Phone：

Target Price：

Remark：

Send Inquiry

Specifications

Product Attribute	Attribute Value
Manufacturer	Micro Commercial Components (MCC)
Product Category	Bipolar Transistors - BJT
RoHS
Maximum DC Collector Current	200 mA
Mounting Style	SMD/SMT
Pd - Power Dissipation	1 W
Product Type	BJTs - Bipolar Transistors
Package / Case	SOT-223-4
Collector- Base Voltage VCBO	60 V
Collector- Emitter Voltage VCEO Max	40 V
Collector-Emitter Saturation Voltage	0.3 V
Emitter- Base Voltage VEBO	6 V
Minimum Operating Temperature	- 55 C
Maximum Operating Temperature	+ 150 C
Gain Bandwidth Product FT	300 MHz
Packaging	Cut Tape or Reel
Brand	Micro Commercial Components (MCC)
Configuration	Single
Continuous Collector Current	200 mA
DC Collector/Base Gain Hfe Min	40
DC Current Gain HFE Max	300 V
Transistor Polarity	NPN
Technology	Si
Factory Pack Quantity	2500
Subcategory	Transistors
